Industrial 1x9 1.25G Dual Fiber SC 40KM 1310nm
型號： 4324-421-1
Industrial 1x9 1.25G Dual Fiber SC 40KM 1310nm
4324-421-1
Feature
l 1×9 package with SC connector
l 1310nm DFB Laser and PIN photodetector
l 40Km transmission with SMF
l +3.3V single power supply
l LVPECL compatible data input/output interface
l Low EMI and excellent ESD protection
l laser safety standard IEC-60825 compliant
l Compatible with RoHS
Application
l Ethernet
l Telecom
Mechanical Dimensions
.png)
Performance specifications
Absolute Maximum Ratings
|
Parameter |
Symbol |
Minimum |
Maximum |
Units |
|
Storage Temperature |
Tst |
-40 |
+85 |
°C |
|
Operating Temperature |
Top |
-40 |
+85 |
°C |
|
Supply Voltage |
Vcc |
0 |
+3.3 |
V |
|
Input voltage |
Vin |
GND |
Vcc |
|
|
Lead Soldering Temperature & Time |
240/10 |
°C/s |
||
Operation Environment
|
Parameter |
Symbol |
Minimum |
Maximum |
Units |
|
Supply Voltage |
Vcc |
3.15 |
3.45 |
V |
|
Ambient operating Temperature |
Top |
-40 |
+85 |
°C |
|
Operating Relative Humidity |
- |
5 |
95 |
% |
有關詳細信息，請在“相關下載”中查看數據表
